ILSCO, Aluminum Mechanical Lug, AU-600
View detailed images (1)

ILSCO, Aluminum Mechanical Lug, AU-600

Aluminum Mechanical Lug, Dual Rated, 600 kcmil - 2 AWG Conductor Range, 1/2 Bolt Size, 0.5" Hex Size

SKUM46587
ManufacturerILSCO
Mfr. Part #AU-600
UPC0783669005684
Points0.18
$18.03

Cross References
Manufacturer Part Number
BURNDY K2A36U

Features
  • Manufactured from high strength 6061-T6 aluminum alloy
  • Electro-Tin plated
  • Suitable for use with either copper or aluminum conductors
  • Chamfered wire entry provides ease of installation
  • Mounting hole spacing from side to side, hole to hole is 0.875"
  • Suitable for use with either copper or aluminum conductors
Downloads
Specification
Type Aluminum Mechanical Lug
Lug Type Two Conductor Dual Rated
Conductor Wire Range 600 kcmil - 2 AWG
Hex Size (In.) 0.50
Bolt Size 1/2
Length (In.) 3.19
Width (In.) 2.41
Standards UL Listed
